Product Overview: A White Glue Film for Light Colors
Our Polyester TPU Film features a built-in hot-melt adhesive layer and comes in a white color. You do not need to apply glue separately. Simply apply heat and pressure, and the film will bond securely.
This film is ideal for creating waterproof and breathable layers on light-colored garments. It simplifies the production process, reduces labor costs, and improves yield rates while minimizing waste.
This Polyester TPU Film has a medium-transparency white matte finish. The white tone helps light-colored fabrics appear cleaner, brighter, and more refined.
Key Data: Water Pressure and Breathability for White Glue Film
The table below shows the water pressure performance of this medium-transparency white adhesive film.
Product drawing
|
Product Series |
Thickness Range (mm) |
Water Pressure Value (mm/H₂O) |
| Medium Transparency White | 0.010 - 012 | 8000 - 10000 |
| Medium Transparency White | 0.013 - 015 | 11000 - 14000 |
| Medium Transparency White | 0.016 - 020 | 13000 - 17000 |
The next table shows breathability test data.
| Product Series | Thickness Range (mm) | Test Version | Breathability Value (g/m²/24hrs) |
| Medium Transparency White | 0.010 - 012 | US Standard 2000 | 7800 |
| Medium Transparency White | 0.013 - 015 | US Standard 2000 | 7500 ± |
| Medium Transparency White | 0.016 - 020 | US Standard 2000 | 6500 - 7000 |
| Medium Transparency White | 0.010 - 012 | Japanese B1 Method | 40000 - 50000 |
| Medium Transparency White | 0.013 - 015 | Japanese B1 Method | 40000 - 50000 |
| Medium Transparency White | 0.016 - 020 | Japanese B1 Method | 40000 - 50000 |
Why Choose This Film: Simple to Use with Great Results
Using our Polyester TPU Film is straightforward. First, cut the film to the required size. Then place it between two layers of fabric and apply a hot press. Recommended processing conditions are 140–160°C, with a pressure of 2–3 kg/cm² and a pressing time of 5–10 seconds. After pressing, allow the material to cool, and the bonding process is complete.
Our technical team can assist with machine setup and parameter adjustment if needed.
The adhesive layer is highly uniform, with minimal thickness variation, ensuring a smooth and even finished product without bubbles or surface irregularities.
Many customers use this adhesive film in down jackets and report that the garments retain a fuller, softer feel compared to liquid adhesive processes, without fabric stiffness.
