Product Overview: A Thick White Bonding Film for Clothes
Our Clear TPU Film is a thick white bonding film designed for clothing applications. The nominal thickness is 0.020 mm, while the actual thickness ranges from 0.016 to 0.020 mm. This film is used as a waterproof and breathable layer for light-colored garments.
A thicker film helps light-colored fabrics appear fuller and enhances the purity of the white appearance. It also prevents the backing fabric color from showing through. This Clear TPU Film features a medium-transparency white matte finish.
It is very easy to use. The operator simply places the film on the fabric, and a hot press completes the bonding process in a single step. No adhesive mixing is required, and no drying time is needed.
Key Data: Water Pressure and Breathability for Thick White Film
The table below shows the water pressure performance of this thick medium-transparency white bonding film.
Product drawing
|
Product Series |
Thickness Range (mm) |
Water Pressure Value (mm/H₂O) |
| Medium Transparency White | 0.010 - 012 | 8000 - 10000 |
| Medium Transparency White | 0.013 - 015 | 11000 - 14000 |
| Medium Transparency White | 0.016 - 020 | 13000 - 17000 |
The next table shows breathability test data.
| Product Series | Thickness Range (mm) | Test Version | Breathability Value (g/m²/24hrs) |
| Medium Transparency White | 0.010 - 012 | US Standard 2000 | 7800 |
| Medium Transparency White | 0.013 - 015 | US Standard 2000 | 7500 ± |
| Medium Transparency White | 0.016 - 020 | US Standard 2000 | 6500 - 7000 |
| Medium Transparency White | 0.010 - 012 | Japanese B1 Method | 40000 - 50000 |
| Medium Transparency White | 0.013 - 015 | Japanese B1 Method | 40000 - 50000 |
| Medium Transparency White | 0.016 - 020 | Japanese B1 Method | 40000 - 50000 |
Why Choose This Film: Higher Production Speed
Using our Clear TPU Film is very simple for operators. The film is placed directly onto the fabric, and bonding is completed using a hot press. There is no adhesive adjustment and no drying time required. Compared with liquid glue processes, this significantly improves production efficiency.
Many clothing factories report that their production output increased by up to 30% after switching to our bonding film.
We precisely control the surface energy of our film, which is one of our key technical advantages. Our self-developed equipment ensures consistent control of this parameter, so every roll performs uniformly. This eliminates batch-to-batch variation, ensuring stable production results.
We also provide on-site technical support. Our technicians can visit your factory to assist with machine setup and operator training. This service is provided free of charge.
