Product Overview: A Thick White Bonding Film for High-End Clothes
Our Crystal White TPU Film is a thick white bonding film designed for high-end apparel. The listed thickness is 0.020 mm, with an actual range of 0.016–0.020 mm. It is used as a waterproof and breathable functional layer in light-colored premium garments.
This thick structure helps light-colored fabrics look fuller and more refined. The white tone enhances visual purity and effectively prevents dark backing fabrics from showing through. The film features a high-transparency white matte finish and is designed for efficient hot-press lamination, allowing one-step bonding without glue mixing or drying time.
Key Data: Water Pressure and Breathability for Thick High-Transparency White Film
Product drawing
|
Product Series |
Thickness Range (mm) |
Water Pressure Value (mm/H₂O) |
| High Transparency White | 0.010 - 0.012 | 8000 - 10000 |
| High Transparency White | 0.013 - 0.015 | 10000 - 13000 |
| High Transparency White | 0.016 - 0.020 | 13000 - 15000 |
Breathability Test Data
| Product Series | Thickness Range (mm) | Test Method | Breathability Value (g/m²/24hrs) |
| High Transparency White | 0.010 - 0.012 | US Standard 2000 | 8500 - 9000 |
| High Transparency White | 0.013 - 0.015 | US Standard 2000 | 8000 - 8500 |
| High Transparency White | 0.016 - 0.020 | US Standard 2000 | ~8000 |
| High Transparency White | 0.010 - 0.012 | Japanese B1 Method | 100,000+ |
| High Transparency White | 0.013 - 0.015 | Japanese B1 Method | 80,000+ |
| High Transparency White | 0.016 - 0.020 | Japanese B1 Method | 80,000+ |
Why Choose This Film: Higher Efficiency in Production
Crystal White TPU Film is designed for fast, stable manufacturing. Workers simply place the film between fabrics and apply heat and pressure to complete bonding in one step. Compared with liquid adhesive processes, it eliminates glue mixing and drying time, significantly improving production efficiency.
Many factories report up to 30% higher output after switching to hot-melt bonding films due to the simplified workflow. The film's surface energy is precisely controlled using in-house equipment, ensuring consistent bonding performance across every roll.
Optional technical support is available. Our technicians can assist with machine setup and process optimization directly at your factory to ensure stable production results.
