Product Overview: The Thickest White Waterproof Film
Our TPU Lamination Film is the thickest white film in our product range. The nominal thickness is 0.025 mm, while the actual thickness ranges from 0.016 to 0.020 mm. This film is used in applications that require the highest level of waterproof performance and mechanical strength, such as professional protective clothing, medical isolation gowns, and industrial waterproof covers.
This TPU Lamination Film features a low-transparency white matte finish. A white waterproof film provides a clean visual appearance. In the medical industry, white is widely used because it conveys hygiene and cleanliness. In protective clothing applications, white is preferred because contamination is easily visible. Our film color is a true pure white, with no grey or blue tint.
Key Data: High Waterproof Values for Demanding Uses
The table below shows the waterproof performance values of this thick white film. A range of 14,000–19,000 mm/H₂O indicates very strong waterproof capability.
Product drawing
|
Product Series |
Thickness Range (mm) |
Water Pressure Value (mm/H₂O) |
| Low Transparency White |
0.010 - 0.012 |
8000 - 12000 |
| Low Transparency White |
0.013 - 0.015 |
11000 - 15000 |
| Low Transparency White |
0.016 - 0.020 |
14000 - 19000 |
Why Choose This Film: Abrasion Resistance and Full Certifications
Our TPU Lamination Film achieves a waterproof rating of 14,000–19,000 mm/H₂O, making it suitable for high-pressure water exposure. Medical protective gowns made with this film can resist penetration from fluids such as blood or other contaminants. Industrial waterproof covers also maintain integrity under long-term outdoor rain exposure.
The thick structure also provides excellent abrasion resistance. In testing, the film was rubbed with sandpaper 500 times without breaking or showing significant damage. This ensures that protective garments made with this material maintain durability even under friction and wear conditions.
Our company holds multiple certifications, including ISO9001, GRS, and OEKO-TEX. Our products comply with EU REACH regulations and contain no phthalates or heavy metals.
